populated some more breakout boards from @aislerhq@aisler.social , bonus picture taken with a microscope
(psst: NNNI26 gets you €10 off throughout the year, multiple times!)
Remote
NNNI
@nnnilabs@mastodon.social
mastodon
4.7.0-beta.1
0
Followers
0
Following
20
Posts
Joined October 26, 2025
Posts
the HMC8043 completes my all-LAN all-SCPI setup! to celebrate, I wrote a script that loads a few useful voltage/current configurations without having to fiddle with the front panel controls
I played with the 34410A for the entire day yesterday and scripting for it is so painless
here, I measured the RMS noise at different NPLC settings and compared it to what it should "ideally" be (decrease with sqrt of integration time, normalized to lowest NPLC)
I finally got myself a 34410A! I impulse-purchased this because:
1. it has a multislope IV ADC which I've always wanted
2. it has LAN, so the first step towards converting my bench to LAN + SCPI
Replying to
@jay@macaw.social
@jay nice article, thanks for sharing! the rate at which the world around me has turned alien is alarming and I find the prospect of the next 50 years to be... unappealing
Replying to
@nixCraft@mastodon.social
@nixCraft@mastodon.social so maybe there is a reason to look forward to the remaining 50 years of my lifespan
fun little project, thanks @aislerhq@aisler.social for making this happen
feels like a good time to do some pcbposting, so here's another run from @aislerhq@aisler.social that I assembled using stencil-and-paste, and then a few minutes in the ultrasonic bath to get them super clean
I swear to god, no ulterior motives!
fresh set of PCBs from @aislerhq@aisler.social
more to come
Replying to
@bruces@mastodon.social
@bruces interesting! I was pleasantly surprised by how easy it was to read a paper by J. C. Maxwell from the 1800s, and it saddens me (and severely triggers my anxiety) to see English go to absolute shit on the internet and the apathy surrounding it
