Matt Zucker @matt_zucker@mastodon.social · Jul 24, 2026

Replying to @matt_zucker@mastodon.social

@unnick@booping.synth.download some quick experimentation in python reveals that for the polynomial for interpolating between 3 points it is sufficient just to use the c200, c020, and c002 coefficients (don't need the xy/xz/yz terms). checking now to see how it lines up against slerp

0

Matt Zucker @matt_zucker@mastodon.social · Jul 24, 2026

Replying to @matt_zucker@mastodon.social

@unnick@booping.synth.download my vague recollection is that approach (1) will give the area property you want but does not reduce to slerp on the edges and (2) does reduce to slerp on the edges but doesn't have the area property but don't take my word for it without trying it out. Both approaches will handle the case of a triangle defined over (1, 0, 0), (0, 1, 0), (0, 0, 1). Let me know if it would be helpful to post a Python/numpy/matplotlib script demoing these approaches

1

0

Matt Zucker @matt_zucker@mastodon.social · Jul 24, 2026

Replying to @unnick@booping.synth.download

@unnick@booping.synth.download here are two things you could try: 1) spherical area coordinates are one way of generalizing barycentric coordinates to the sphere, check out https://brsr.github.io/2023/11/04/spherical-areal.html 2) you could fit a homogeneous polynomial of the form c200*x^2 + c020*y^2 + c002*x^2 + c110*x*y + c101*x*z + c011*y*z and sample it. this framework is described in Alfeld et al. 1996 "Bernstein-Bézier polynomials on spheres and sphere-like surfaces." https://www.researchgate.net/profile/Mike-Neamtu/publication/2509001_Bernstein-B'ezier_Polynomials_on_Spheres_and_Sphere-Like_Surfaces/links/540daaef0cf2d8daaacc78c4/Bernstein-Bezier-Polynomials-on-Spheres-and-Sphere-Like-Surfaces.pdf I have played with both approaches and...

2

1

0

Matt Zucker @matt_zucker@mastodon.social · May 02, 2026

Replying to @Gmatom@mastodon.social

@Gmatom instantly recognizable!

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

Replying to @kbob@chaos.social

@kbob@chaos.social more like the latter

1

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

Replying to @bazzargh@hachyderm.io

@bazzargh@hachyderm.io neat!

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

Replying to @kbob@chaos.social

@kbob@chaos.social For PBC on a square grid you can use an extra layer of grid squares outside the tile, but they are not fixed – they copy values from the opposite side of the domain. See e.g. page 3 of https://www.josstam.com/_files/ugd/cf1fd6_9989229efbd34a26ba5ccd913721a2ac.pdf But I'm not using square grids - that would be the finite difference method. Instead I use triangle meshes with the finite element method. Much better for shapes like pentagons with no right angles.

1

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

Replying to @jannem@fosstodon.org

@jannem@fosstodon.org Yep!

1

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

Replying to @matt_zucker@mastodon.social

@jannem@fosstodon.org Flips? Not sure how to deal with them with my folded-in-half (symmetric) edges, so I would have trouble answering this without thinking a lot harder.

0

1

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

Replying to @jannem@fosstodon.org

@jannem@fosstodon.org not quite torus geometry. A torus is a manifold (https://en.wikipedia.org/wiki/Manifold) and my folded-square-thing is most definitely not. Torus would be the same as the "Pac-Man" periodic boundary conditions I alluded to earlier. That gives two distinct edges that loosely correspond to the "equator" and "prime meridian" of the torus. Yes for multiple patterns you need to have multiple sheets sharing the same edge. (cont'd...)

0

4

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

Replying to @matt_zucker@mastodon.social

If you liked this thread, check out my very infrequently-updated coding blog at https://mzucker.github.io/ for other #MathArt projects and miscellaneous tinkering. And feel free to reply with questions – I'll do my best to answer them here.

6

2

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

Replying to @matt_zucker@mastodon.social

The wooden tiles were exhibited previously at the 2026 JMM art exhibition, and I just learned that the spherical tilings and red squares were accepted for the art exhibition at Bridges Galway 2026 from August 5-8: https://www.bridgesmathart.org/b2026/ Come check them out if you're in the neighborhood!

5

11

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

Replying to @matt_zucker@mastodon.social

And after a few extra hacks to mitigate some unpleasant visual artifacts, it all Just Works™. Of course I wrote an academic paper with all of the gory details – look for it in the upcoming Bridges 2026 conference proceedings. Here's a figure that gives a taste of what the software does.

4

12

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

Replying to @matt_zucker@mastodon.social

I had to write a homemade finite element method (FEM, https://en.wikipedia.org/wiki/Finite_element_method) solver to simulate the Gray-Scott model on this weirdo domain. FEM solvers tend to throw up their hands and quit when you point them at non-manifold geometry like the folded and glued square, but I hollered at mine until it started behaving.

2

1

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

Replying to @matt_zucker@mastodon.social

You can definitely play with symmetry when laying out the tiles. Here's those same red plastic tiles from before, and again after re-arranging to make a composition with 90° rotational symmetry. How many unique tile designs do you see here? (Hint, it's the same in both images.)

0

14

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

Replying to @matt_zucker@mastodon.social

Want more than one tile design? NP, just glue together multiple sheets along their shared edge. If you look closely at the wooden tiles you'll see there are three distinct tile designs. And here are two different icosahedron tilings, one with a single tile design, and one with every tile unique.

15

2

5

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

Replying to @matt_zucker@mastodon.social

Now all four corners of the square are mathematically considered to be the same point, as are any set of points along a boundary edge that are all the same distance away from the corner. BTW when solving the PDEs, we don't consider the effects of the folds, just the "glue".

1

17

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

Replying to @matt_zucker@mastodon.social

Here's what it looks like, starting with a square sheet (a). First, fold it into quarters (b), then fold diagonally to put all of the boundary edges on top of each other (c). Finally, glue all of the edges together (d).

1

18

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

Replying to @matt_zucker@mastodon.social

But until I started this project, I don't think anyone was daft enough to make reaction-diffusion Truchet tiles that match up no matter how you reorient them. The central trick is to solve the Gray-Scott PDEs on an unusual topological domain that collapses all of the edges into a single segment.

2

1

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

Replying to @matt_zucker@mastodon.social

More interesting RD tilings are possible. Recently, Vladimir Bulatov has been making some really cool patterns with his SymSim software – check it out at https://symmhub.github.io/SymmHub/apps/symsim/gray_scott/index.html

3

20

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

Replying to @matt_zucker@mastodon.social

Making RD patterns that tile like wallpaper is easy – apply periodic boundary conditions (PBCs, https://en.wikipedia.org/wiki/Periodic_boundary_conditions) when solving the PDEs. PBCs are like the old-school Pac-Man arcade game: crossing the left side of the "screen" warps you to the right side, and ditto for top/bottom.

0

1

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

Replying to @matt_zucker@mastodon.social

Making reaction-diffusion patterns amounts to solving a system of partial differential equations (PDEs) – the Gray-Scott model – that describe the simulated chemical reaction. The formula might look like Greek, but it's not too exotic from a math/coding standpoint.

0

22

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

Replying to @matt_zucker@mastodon.social

OK, so what's "reaction-diffusion" then? In brief, it's a mathematical model of a chemical reaction that produces patterns similar to many found in nature. For more info, see https://www.karlsims.com/rd.html and/or https://mrob.com/pub/comp/xmorphia/index.html

3

25

2

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

Replying to @matt_zucker@mastodon.social

RE: https://mastodon.social/@matt_zucker/114389429207956266 (BTW if these orbs look familiar, maybe you saw the thread I posted about a year ago about similar work I did.)

2

26

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

Replying to @matt_zucker@mastodon.social

"Truchet tiling" means that that each tile can be rotated in place or swapped with another of the same shape without breaking up the pattern. To get this you need the tiles' edges to all be identical and mirror-symmetric. This is not obvious at first glance when looking at the overall tiling, IMO.

4

1

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

Replying to @matt_zucker@mastodon.social

Oh, and here are some planar variants I made, too. The left one is CNC-machined walnut and maple, because it seemed like a really cool idea before I realized exactly how much hand-sanding would be involved (too much, it was too much sanding). The right one is 3D-printed nylon.

3

28

0

Matt Zucker @matt_zucker@mastodon.social · Apr 16, 2026

New #MathArt sculptures: reaction-diffusion Truchet tilings of the sphere! These are made from 3D-printed nylon and each individual tile can be removed/replaced.

If you think these look cool or interesting, stick around to learn a little bit about how they were made and the math behind them... 🧵

33

31

21
